Reverse Phase LED Dimmer for Poultry Lighting System ACD-24A-3D 24A 5280W

Introduction

The ACD-24A-3D dimming controller is a high-precision, intelligent dimming device equipped with a built-in timetable function. It is specifically designed to manage the brightness of LED lamps in poultry and livestock breeding facilities, such as chicken houses and pig houses.

The built-in timetable feature automatically adjusts the brightness of the LED lights based on a preset schedule, optimizing the management of the breeding cycle. Additionally, the controller can integrate with the 0-10V signal from an upper-level breeding controller, allowing the brightness of the LED lights to be controlled by the primary system.

For greater flexibility, the ACD-24A-3D also offers a manual control function, enabling users to directly adjust the light brightness as needed.

Features

• World-leading DualMos Trailing-Edge AC Phase-Cutting Dimming Technology: Ensures 0-100% flicker-free dimming throughout the entire process.
• 0-100% Brightness Dimming: Simulates sunrise and sunset, enhancing animal welfare.
• Built-in Farming Timetable: Includes Ramp Minutes for realistic sunrise and sunset simulations.
• Slave Mode Support: Compatible with 0-10V control signals, with configurable thresholds.
• Manual Dimming: Offers smooth and soft dimming for precise control.
• Power-Off Memory Function: Automatically resumes operation based on the original timetable after a power failure and restart.
• Manual Mode Power-Down Memory: Retains settings even during power interruptions.
• 7-inch 600×1024 IPS Capacitive Touch LCD Screen: Provides a clear and responsive interface.
• Wall-Mounted Installation: Easy and space-saving setup.
• IP65 Waterproof Rating: Ensures durability and reliability in challenging environments.
